If you are a fan of compact luminaires, the Edda spotlight is perfect for you. The design of this adjustable 3-phase track spot is really distinctive with the incorporated driver track adapter. You can choose from three sizes and a wide range of light colours and accessories, which makes Edda popular in shops, showrooms and hospitality establishments.
Products.
EDDA M
-
Accentuates the freshness of fruit and vegetables.
-
Warm yellowish light gives a perfect appearance to cheese and other dairy products.
-
Fresh and cooked meats have a saturated red colour under this light. A boost of red for the meat counter.
-
Bluish white light promotes freshness of fish and seafood.
-
This light colour has a light brown tinge to give an oven-fresh appearance to crusty bakery products.
-
Optimized light spectrum for perfect fashion presentation.
-
This LED module offers the high quality of light that is needed for displaying high value exhibits. The average value of the Art series is an impressive CRI 98. MacAdam 2 ellipses are provided in this special product category to also provide an outstanding color consistency.
-
Spectral LED matches natural light over the visible spectrum.
-
For spot and accent lighting in fashion, retail, hospitality and supermarket applications.
-
Dim to a warmer color from 3000K to 1800K for creating the right atmosphere.
-
Digital dimming interface.
-
Wireless lighting control based on Bluetooth.
-
The luminaire is as well available for 1-phase tracks.
-
The clear glass is protecting the light source and reflector from dust and other dirt that could enter the optical part of the luminaire.
-
The frosted glass is protecting the light source and reflector from dust and other dirt that could enter the optical part of the luminaire. In addition to that, it also widens the beam and creates a different footprint.
-
Honeycombs are widely used to reduce the direct glare. Luminaires with honeycombs have usually a tighter beam.
-
Shape the light by using barn doors. Two side flaps closed together produce a slim light shape like light passing through a partially open door. All four doors closed together will produce a square focussed beam of light.
-
Warranty on quality in years.
-
Replaceable (LED only) light source by a professional.
-
Replaceable control gear by a professional.
| Article Number | Luminous Flux | Connected Load | Cct | Cri | Color Housing | Beam Angle |
|---|---|---|---|---|---|---|
| 2.028B0A830001500000 | 1750Lm | 14W | 3000K | (RA) >80 | White (RAL 9003) | 15° |
| 2.028B0A930001500000 | 1450Lm | 14W | 3000K | (RA) >90 | White (RAL 9003) | 15° |
| 2.028B0A940001500000 | 1550Lm | 14W | 4000K | (RA) >90 | White (RAL 9003) | 15° |
| 2.028B0B830001500000 | 1750Lm | 14W | 3000K | (RA) >80 | Black (RAL 9005) | 15° |
| 2.028B0B930001500000 | 1450Lm | 14W | 3000K | (RA) >90 | Black (RAL 9005) | 15° |
| 2.028B0B940001500000 | 1550Lm | 14W | 4000K | (RA) >90 | Black (RAL 9005) | 15° |
| 2.028B0C830001500000 | 1750Lm | 14W | 3000K | (RA) >80 | Grey (RAL 9006) | 15° |
| 2.028B0C930001500000 | 1450Lm | 14W | 3000K | (RA) >90 | Grey (RAL 9006) | 15° |
| 2.028B0C940001500000 | 1550Lm | 14W | 4000K | (RA) >90 | Grey (RAL 9006) | 15° |
| 2.028C0A840001500000 | 1800Lm | 14W | 4000K | (RA) >80 | White (RAL 9003) | 15° |
| 2.028C0A930001500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | White (RAL 9003) | 15° |
| 2.028C0A940001500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | White (RAL 9003) | 15° |
| 2.028C0B840001500000 | 1800Lm | 14W | 4000K | (RA) >80 | Black (RAL 9005) | 15° |
| 2.028C0B930001500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Black (RAL 9005) | 15° |
| 2.028C0B940001500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Black (RAL 9005) | 15° |
| 2.028C0C840001500000 | 1800Lm | 14W | 4000K | (RA) >80 | Grey (RAL 9006) | 15° |
| 2.028C0C930001500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Grey (RAL 9006) | 15° |
| 2.028C0C940001500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Grey (RAL 9006) | 15° |
| 2.028D0A830001500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | White (RAL 9003) | 15° |
| 2.028D0A840001500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | White (RAL 9003) | 15° |
| 2.028D0B830001500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Black (RAL 9005) | 15° |
| 2.028D0B840001500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Black (RAL 9005) | 15° |
| 2.028D0C830001500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Grey (RAL 9006) | 15° |
| 2.028D0C840001500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Grey (RAL 9006) | 15° |
| 2.028E0A830001500000 | 3250Lm | 27W | 3000K | (RA) >80 | White (RAL 9003) | 15° |
| 2.028E0A930001500000 | 3000Lm | 30W | 3000K | (RA) >90 | White (RAL 9003) | 15° |
| 2.028E0A940001500000 | 3250Lm | 30W | 4000K | (RA) >90 | White (RAL 9003) | 15° |
| 2.028E0B830001500000 | 3250Lm | 27W | 3000K | (RA) >80 | Black (RAL 9005) | 15° |
| 2.028E0B930001500000 | 3000Lm | 30W | 3000K | (RA) >90 | Black (RAL 9005) | 15° |
| 2.028E0B940001500000 | 3250Lm | 30W | 4000K | (RA) >90 | Black (RAL 9005) | 15° |
| 2.028E0C830001500000 | 3250Lm | 27W | 3000K | (RA) >80 | Grey (RAL 9006) | 15° |
| 2.028E0C930001500000 | 3000Lm | 30W | 3000K | (RA) >90 | Grey (RAL 9006) | 15° |
| 2.028E0C940001500000 | 3250Lm | 30W | 4000K | (RA) >90 | Grey (RAL 9006) | 15° |
| 2.028F0A840001500000 | 3350Lm | 27W | 4000K | (RA) >80 | White (RAL 9003) | 15° |
| 2.028F0B840001500000 | 3350Lm | 27W | 4000K | (RA) >80 | Black (RAL 9005) | 15° |
| 2.028F0C840001500000 | 3350Lm | 27W | 4000K | (RA) >80 | Grey (RAL 9006) | 15° |
| 2.028B0A830003000000 | 1750Lm | 14W | 3000K | (RA) >80 | White (RAL 9003) | 30° |
| 2.028B0A930003000000 | 1450Lm | 14W | 3000K | (RA) >90 | White (RAL 9003) | 30° |
| 2.028B0A940003000000 | 1550Lm | 14W | 4000K | (RA) >90 | White (RAL 9003) | 30° |
| 2.028B0B830003000000 | 1750Lm | 14W | 3000K | (RA) >80 | Black (RAL 9005) | 30° |
| 2.028B0B930003000000 | 1450Lm | 14W | 3000K | (RA) >90 | Black (RAL 9005) | 30° |
| 2.028B0B940003000000 | 1550Lm | 14W | 4000K | (RA) >90 | Black (RAL 9005) | 30° |
| 2.028B0C830003000000 | 1750Lm | 14W | 3000K | (RA) >80 | Grey (RAL 9006) | 30° |
| 2.028B0C930003000000 | 1450Lm | 14W | 3000K | (RA) >90 | Grey (RAL 9006) | 30° |
| 2.028B0C940003000000 | 1550Lm | 14W | 4000K | (RA) >90 | Grey (RAL 9006) | 30° |
| 2.028C0A840003000000 | 1800Lm | 14W | 4000K | (RA) >80 | White (RAL 9003) | 30° |
| 2.028C0A930003000000 | 2000Lm | 18.5W | 3000K | (RA) >90 | White (RAL 9003) | 30° |
| 2.028C0A940003000000 | 2150Lm | 18.5W | 4000K | (RA) >90 | White (RAL 9003) | 30° |
| 2.028C0B840003000000 | 1800Lm | 14W | 4000K | (RA) >80 | Black (RAL 9005) | 30° |
| 2.028C0B930003000000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Black (RAL 9005) | 30° |
| 2.028C0B940003000000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Black (RAL 9005) | 30° |
| 2.028C0C840003000000 | 1800Lm | 14W | 4000K | (RA) >80 | Grey (RAL 9006) | 30° |
| 2.028C0C930003000000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Grey (RAL 9006) | 30° |
| 2.028C0C940003000000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Grey (RAL 9006) | 30° |
| 2.028D0A830003000000 | 2400Lm | 18.5W | 3000K | (RA) >80 | White (RAL 9003) | 30° |
| 2.028D0A840003000000 | 2500Lm | 18.5W | 4000K | (RA) >80 | White (RAL 9003) | 30° |
| 2.028D0B830003000000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Black (RAL 9005) | 30° |
| 2.028D0B840003000000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Black (RAL 9005) | 30° |
| 2.028D0C830003000000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Grey (RAL 9006) | 30° |
| 2.028D0C840003000000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Grey (RAL 9006) | 30° |
| 2.028E0A830003000000 | 3250Lm | 27W | 3000K | (RA) >80 | White (RAL 9003) | 30° |
| 2.028E0A930003000000 | 3000Lm | 30W | 3000K | (RA) >90 | White (RAL 9003) | 30° |
| 2.028E0A940003000000 | 3250Lm | 30W | 4000K | (RA) >90 | White (RAL 9003) | 30° |
| 2.028E0B830003000000 | 3250Lm | 27W | 3000K | (RA) >80 | Black (RAL 9005) | 30° |
| 2.028E0B930003000000 | 3000Lm | 30W | 3000K | (RA) >90 | Black (RAL 9005) | 30° |
| 2.028E0B940003000000 | 3250Lm | 30W | 4000K | (RA) >90 | Black (RAL 9005) | 30° |
| 2.028E0C830003000000 | 3250Lm | 27W | 3000K | (RA) >80 | Grey (RAL 9006) | 30° |
| 2.028E0C930003000000 | 3000Lm | 30W | 3000K | (RA) >90 | Grey (RAL 9006) | 30° |
| 2.028E0C940003000000 | 3250Lm | 30W | 4000K | (RA) >90 | Grey (RAL 9006) | 30° |
| 2.028F0A840003000000 | 3350Lm | 27W | 4000K | (RA) >80 | White (RAL 9003) | 30° |
| 2.028F0B840003000000 | 3350Lm | 27W | 4000K | (RA) >80 | Black (RAL 9005) | 30° |
| 2.028F0C840003000000 | 3350Lm | 27W | 4000K | (RA) >80 | Grey (RAL 9006) | 30° |
| 2.028B0A830004500000 | 1750Lm | 14W | 3000K | (RA) >80 | White (RAL 9003) | 45° |
| 2.028B0A930004500000 | 1450Lm | 14W | 3000K | (RA) >90 | White (RAL 9003) | 45° |
| 2.028B0A940004500000 | 1550Lm | 14W | 4000K | (RA) >90 | White (RAL 9003) | 45° |
| 2.028B0B830004500000 | 1750Lm | 14W | 3000K | (RA) >80 | Black (RAL 9005) | 45° |
| 2.028B0B930004500000 | 1450Lm | 14W | 3000K | (RA) >90 | Black (RAL 9005) | 45° |
| 2.028B0B940004500000 | 1550Lm | 14W | 4000K | (RA) >90 | Black (RAL 9005) | 45° |
| 2.028B0C830004500000 | 1750Lm | 14W | 3000K | (RA) >80 | Grey (RAL 9006) | 45° |
| 2.028B0C930004500000 | 1450Lm | 14W | 3000K | (RA) >90 | Grey (RAL 9006) | 45° |
| 2.028B0C940004500000 | 1550Lm | 14W | 4000K | (RA) >90 | Grey (RAL 9006) | 45° |
| 2.028C0A840004500000 | 1800Lm | 14W | 4000K | (RA) >80 | White (RAL 9003) | 45° |
| 2.028C0A930004500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | White (RAL 9003) | 45° |
| 2.028C0A940004500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | White (RAL 9003) | 45° |
| 2.028C0B840004500000 | 1800Lm | 14W | 4000K | (RA) >80 | Black (RAL 9005) | 45° |
| 2.028C0B930004500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Black (RAL 9005) | 45° |
| 2.028C0B940004500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Black (RAL 9005) | 45° |
| 2.028C0C840004500000 | 1800Lm | 14W | 4000K | (RA) >80 | Grey (RAL 9006) | 45° |
| 2.028C0C930004500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Grey (RAL 9006) | 45° |
| 2.028C0C940004500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Grey (RAL 9006) | 45° |
| 2.028D0A830004500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | White (RAL 9003) | 45° |
| 2.028D0A840004500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | White (RAL 9003) | 45° |
| 2.028D0B830004500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Black (RAL 9005) | 45° |
| 2.028D0B840004500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Black (RAL 9005) | 45° |
| 2.028D0C830004500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Grey (RAL 9006) | 45° |
| 2.028D0C840004500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Grey (RAL 9006) | 45° |
| 2.028E0A830004500000 | 3250Lm | 27W | 3000K | (RA) >80 | White (RAL 9003) | 45° |
| 2.028E0A930004500000 | 3000Lm | 30W | 3000K | (RA) >90 | White (RAL 9003) | 45° |
| 2.028E0A940004500000 | 3250Lm | 30W | 4000K | (RA) >90 | White (RAL 9003) | 45° |
| 2.028E0B830004500000 | 3250Lm | 27W | 3000K | (RA) >80 | Black (RAL 9005) | 45° |
| 2.028E0B930004500000 | 3000Lm | 30W | 3000K | (RA) >90 | Black (RAL 9005) | 45° |
| 2.028E0B940004500000 | 3250Lm | 30W | 4000K | (RA) >90 | Black (RAL 9005) | 45° |
| 2.028E0C830004500000 | 3250Lm | 27W | 3000K | (RA) >80 | Grey (RAL 9006) | 45° |
| 2.028E0C930004500000 | 3000Lm | 30W | 3000K | (RA) >90 | Grey (RAL 9006) | 45° |
| 2.028E0C940004500000 | 3250Lm | 30W | 4000K | (RA) >90 | Grey (RAL 9006) | 45° |
| 2.028F0A840004500000 | 3350Lm | 27W | 4000K | (RA) >80 | White (RAL 9003) | 45° |
| 2.028F0B840004500000 | 3350Lm | 27W | 4000K | (RA) >80 | Black (RAL 9005) | 45° |
| 2.028F0C840004500000 | 3350Lm | 27W | 4000K | (RA) >80 | Grey (RAL 9006) | 45° |
| 2.028B0A830005500000 | 1750Lm | 14W | 3000K | (RA) >80 | White (RAL 9003) | 55° |
| 2.028B0A930005500000 | 1450Lm | 14W | 3000K | (RA) >90 | White (RAL 9003) | 55° |
| 2.028B0A940005500000 | 1550Lm | 14W | 4000K | (RA) >90 | White (RAL 9003) | 55° |
| 2.028B0B830005500000 | 1750Lm | 14W | 3000K | (RA) >80 | Black (RAL 9005) | 55° |
| 2.028B0B930005500000 | 1450Lm | 14W | 3000K | (RA) >90 | Black (RAL 9005) | 55° |
| 2.028B0B940005500000 | 1550Lm | 14W | 4000K | (RA) >90 | Black (RAL 9005) | 55° |
| 2.028B0C830005500000 | 1750Lm | 14W | 3000K | (RA) >80 | Grey (RAL 9006) | 55° |
| 2.028B0C930005500000 | 1450Lm | 14W | 3000K | (RA) >90 | Grey (RAL 9006) | 55° |
| 2.028B0C940005500000 | 1550Lm | 14W | 4000K | (RA) >90 | Grey (RAL 9006) | 55° |
| 2.028C0A840005500000 | 1800Lm | 14W | 4000K | (RA) >80 | White (RAL 9003) | 55° |
| 2.028C0A930005500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | White (RAL 9003) | 55° |
| 2.028C0A940005500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | White (RAL 9003) | 55° |
| 2.028C0B840005500000 | 1800Lm | 14W | 4000K | (RA) >80 | Black (RAL 9005) | 55° |
| 2.028C0B930005500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Black (RAL 9005) | 55° |
| 2.028C0B940005500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Black (RAL 9005) | 55° |
| 2.028C0C840005500000 | 1800Lm | 14W | 4000K | (RA) >80 | Grey (RAL 9006) | 55° |
| 2.028C0C930005500000 | 2000Lm | 18.5W | 3000K | (RA) >90 | Grey (RAL 9006) | 55° |
| 2.028C0C940005500000 | 2150Lm | 18.5W | 4000K | (RA) >90 | Grey (RAL 9006) | 55° |
| 2.028D0A830005500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | White (RAL 9003) | 55° |
| 2.028D0A840005500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | White (RAL 9003) | 55° |
| 2.028D0B830005500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Black (RAL 9005) | 55° |
| 2.028D0B840005500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Black (RAL 9005) | 55° |
| 2.028D0C830005500000 | 2400Lm | 18.5W | 3000K | (RA) >80 | Grey (RAL 9006) | 55° |
| 2.028D0C840005500000 | 2500Lm | 18.5W | 4000K | (RA) >80 | Grey (RAL 9006) | 55° |
| 2.028E0A830005500000 | 3250Lm | 27W | 3000K | (RA) >80 | White (RAL 9003) | 55° |
| 2.028E0A930005500000 | 3000Lm | 30W | 3000K | (RA) >90 | White (RAL 9003) | 55° |
| 2.028E0A940005500000 | 3250Lm | 30W | 4000K | (RA) >90 | White (RAL 9003) | 55° |
| 2.028E0B830005500000 | 3250Lm | 27W | 3000K | (RA) >80 | Black (RAL 9005) | 55° |
| 2.028E0B930005500000 | 3000Lm | 30W | 3000K | (RA) >90 | Black (RAL 9005) | 55° |
| 2.028E0B940005500000 | 3250Lm | 30W | 4000K | (RA) >90 | Black (RAL 9005) | 55° |
| 2.028E0C830005500000 | 3250Lm | 27W | 3000K | (RA) >80 | Grey (RAL 9006) | 55° |
| 2.028E0C930005500000 | 3000Lm | 30W | 3000K | (RA) >90 | Grey (RAL 9006) | 55° |
| 2.028E0C940005500000 | 3250Lm | 30W | 4000K | (RA) >90 | Grey (RAL 9006) | 55° |
| 2.028F0A840005500000 | 3350Lm | 27W | 4000K | (RA) >80 | White (RAL 9003) | 55° |
| 2.028F0B840005500000 | 3350Lm | 27W | 4000K | (RA) >80 | Black (RAL 9005) | 55° |
| 2.028F0C840005500000 | 3350Lm | 27W | 4000K | (RA) >80 | Grey (RAL 9006) | 55° |
| 2.028D0B000AR1500000 | 2750Lm | 30W | Art | (RA) >98 Art | Black (RAL 9005) | 15° |
| 2.028D0C000AR1500000 | 2750Lm | 30W | Art | (RA) >98 Art | Grey (RAL 9006) | 15° |
| 2.028D0A000AR1500000 | 2750Lm | 30W | Art | (RA) >98 Art | White (RAL 9003) | 15° |
| 2.028D0B000AR3000000 | 2750Lm | 30W | Art | (RA) >98 Art | Black (RAL 9005) | 30° |
| 2.028D0C000AR3000000 | 2750Lm | 30W | Art | (RA) >98 Art | Grey (RAL 9006) | 30° |
| 2.028D0A000AR3000000 | 2750Lm | 30W | Art | (RA) >98 Art | White (RAL 9003) | 30° |
| 2.028D0B000AR4500000 | 2750Lm | 30W | Art | (RA) >98 Art | Black (RAL 9005) | 45° |
| 2.028D0C000AR4500000 | 2750Lm | 30W | Art | (RA) >98 Art | Grey (RAL 9006) | 45° |
| 2.028D0A000AR4500000 | 2750Lm | 30W | Art | (RA) >98 Art | White (RAL 9003) | 45° |
| 2.028D0B000AR5500000 | 2750Lm | 30W | Art | (RA) >98 Art | Black (RAL 9005) | 55° |
| 2.028D0C000AR5500000 | 2750Lm | 30W | Art | (RA) >98 Art | Grey (RAL 9006) | 55° |
| 2.028D0A000AR5500000 | 2750Lm | 30W | Art | (RA) >98 Art | White (RAL 9003) | 55° |
| 2.028C0B000BA1500000 | 2000Lm | 30W | Bakery | Bakery | Black (RAL 9005) | 15° |
| 2.028C0C000BA1500000 | 2000Lm | 30W | Bakery | Bakery | Grey (RAL 9006) | 15° |
| 2.028C0A000BA1500000 | 2000Lm | 30W | Bakery | Bakery | White (RAL 9003) | 15° |
| 2.028C0B000BA3000000 | 2000Lm | 30W | Bakery | Bakery | Black (RAL 9005) | 30° |
| 2.028C0C000BA3000000 | 2000Lm | 30W | Bakery | Bakery | Grey (RAL 9006) | 30° |
| 2.028C0A000BA3000000 | 2000Lm | 30W | Bakery | Bakery | White (RAL 9003) | 30° |
| 2.028C0B000BA4500000 | 2000Lm | 30W | Bakery | Bakery | Black (RAL 9005) | 45° |
| 2.028C0C000BA4500000 | 2000Lm | 30W | Bakery | Bakery | Grey (RAL 9006) | 45° |
| 2.028C0A000BA4500000 | 2000Lm | 30W | Bakery | Bakery | White (RAL 9003) | 45° |
| 2.028C0B000BA5500000 | 2000Lm | 30W | Bakery | Bakery | Black (RAL 9005) | 55° |
| 2.028C0C000BA5500000 | 2000Lm | 30W | Bakery | Bakery | Grey (RAL 9006) | 55° |
| 2.028C0A000BA5500000 | 2000Lm | 30W | Bakery | Bakery | White (RAL 9003) | 55° |
| 2.028E0B000FA1500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Black (RAL 9005) | 15° |
| 2.028E0C000FA1500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Grey (RAL 9006) | 15° |
| 2.028E0A000FA1500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | White (RAL 9003) | 15° |
| 2.028E0B000FA3000000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Black (RAL 9005) | 30° |
| 2.028E0C000FA3000000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Grey (RAL 9006) | 30° |
| 2.028E0A000FA3000000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | White (RAL 9003) | 30° |
| 2.028E0B000FA4500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Black (RAL 9005) | 45° |
| 2.028E0C000FA4500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Grey (RAL 9006) | 45° |
| 2.028E0A000FA4500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | White (RAL 9003) | 45° |
| 2.028E0B000FA5500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Black (RAL 9005) | 55° |
| 2.028E0C000FA5500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | Grey (RAL 9006) | 55° |
| 2.028E0A000FA5500000 | 2900Lm | 30W | Fashion | (RA) >97 Fashion | White (RAL 9003) | 55° |
| 2.028E0B000FI1500000 | 3200Lm | 30W | Fish | Fish | Black (RAL 9005) | 15° |
| 2.028E0C000FI1500000 | 3200Lm | 30W | Fish | Fish | Grey (RAL 9006) | 15° |
| 2.028E0A000FI1500000 | 3200Lm | 30W | Fish | Fish | White (RAL 9003) | 15° |
| 2.028E0B000FI3000000 | 3200Lm | 30W | Fish | Fish | Black (RAL 9005) | 30° |
| 2.028E0C000FI3000000 | 3200Lm | 30W | Fish | Fish | Grey (RAL 9006) | 30° |
| 2.028E0A000FI3000000 | 3200Lm | 30W | Fish | Fish | White (RAL 9003) | 30° |
| 2.028E0B000FI4500000 | 3200Lm | 30W | Fish | Fish | Black (RAL 9005) | 45° |
| 2.028E0C000FI4500000 | 3200Lm | 30W | Fish | Fish | Grey (RAL 9006) | 45° |
| 2.028E0A000FI4500000 | 3200Lm | 30W | Fish | Fish | White (RAL 9003) | 45° |
| 2.028E0B000FI5500000 | 3200Lm | 30W | Fish | Fish | Black (RAL 9005) | 55° |
| 2.028E0C000FI5500000 | 3200Lm | 30W | Fish | Fish | Grey (RAL 9006) | 55° |
| 2.028E0A000FI5500000 | 3200Lm | 30W | Fish | Fish | White (RAL 9003) | 55° |
| 2.028D0B000FR1500000 | 2700Lm | 30W | 3000K | Fruit | Black (RAL 9005) | 15° |
| 2.028D0C000FR1500000 | 2700Lm | 30W | 3000K | Fruit | Grey (RAL 9006) | 15° |
| 2.028D0A000FR1500000 | 2700Lm | 30W | 3000K | Fruit | White (RAL 9003) | 15° |
| 2.028D0B000FR3000000 | 2700Lm | 30W | 3000K | Fruit | Black (RAL 9005) | 30° |
| 2.028D0C000FR3000000 | 2700Lm | 30W | 3000K | Fruit | Grey (RAL 9006) | 30° |
| 2.028D0A000FR3000000 | 2700Lm | 30W | 3000K | Fruit | White (RAL 9003) | 30° |
| 2.028D0B000FR4500000 | 2700Lm | 30W | 3000K | Fruit | Black (RAL 9005) | 45° |
| 2.028D0C000FR4500000 | 2700Lm | 30W | 3000K | Fruit | Grey (RAL 9006) | 45° |
| 2.028D0A000FR4500000 | 2700Lm | 30W | 3000K | Fruit | White (RAL 9003) | 45° |
| 2.028D0B000FR5500000 | 2700Lm | 30W | 3000K | Fruit | Black (RAL 9005) | 55° |
| 2.028D0C000FR5500000 | 2700Lm | 30W | 3000K | Fruit | Grey (RAL 9006) | 55° |
| 2.028D0A000FR5500000 | 2700Lm | 30W | 3000K | Fruit | White (RAL 9003) | 55° |
| 2.028C0B000ME1500000 | 1950Lm | 30W | Meat | Meat | Black (RAL 9005) | 15° |
| 2.028C0C000ME1500000 | 1950Lm | 30W | Meat | Meat | Grey (RAL 9006) | 15° |
| 2.028C0A000ME1500000 | 1950Lm | 30W | Meat | Meat | White (RAL 9003) | 15° |
| 2.028C0B000ME3000000 | 1950Lm | 30W | Meat | Meat | Black (RAL 9005) | 30° |
| 2.028C0C000ME3000000 | 1950Lm | 30W | Meat | Meat | Grey (RAL 9006) | 30° |
| 2.028C0A000ME3000000 | 1950Lm | 30W | Meat | Meat | White (RAL 9003) | 30° |
| 2.028C0B000ME4500000 | 1950Lm | 30W | Meat | Meat | Black (RAL 9005) | 45° |
| 2.028C0C000ME4500000 | 1950Lm | 30W | Meat | Meat | Grey (RAL 9006) | 45° |
| 2.028C0A000ME4500000 | 1950Lm | 30W | Meat | Meat | White (RAL 9003) | 45° |
| 2.028C0B000ME5500000 | 1950Lm | 30W | Meat | Meat | Black (RAL 9005) | 55° |
| 2.028C0C000ME5500000 | 1950Lm | 30W | Meat | Meat | Grey (RAL 9006) | 55° |
| 2.028C0A000ME5500000 | 1950Lm | 30W | Meat | Meat | White (RAL 9003) | 55° |
| 2.028D0B930TH1500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Black (RAL 9005) | 15° |
| 2.028D0C930TH1500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Grey (RAL 9006) | 15° |
| 2.028D0A930TH1500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | White (RAL 9003) | 15° |
| 2.028D0B930TH3000000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Black (RAL 9005) | 30° |
| 2.028D0C930TH3000000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Grey (RAL 9006) | 30° |
| 2.028D0A930TH3000000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | White (RAL 9003) | 30° |
| 2.028D0B930TH4500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Black (RAL 9005) | 45° |
| 2.028D0C930TH4500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Grey (RAL 9006) | 45° |
| 2.028D0A930TH4500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | White (RAL 9003) | 45° |
| 2.028D0B930TH5500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Black (RAL 9005) | 55° |
| 2.028D0C930TH5500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | Grey (RAL 9006) | 55° |
| 2.028D0A930TH5500000 | 2300Lm | 30W | 3000K | (RA) >98 Full spec | White (RAL 9003) | 55° |
| 2.028D0B940TH1500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Black (RAL 9005) | 15° |
| 2.028D0C940TH1500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Grey (RAL 9006) | 15° |
| 2.028D0A940TH1500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | White (RAL 9003) | 15° |
| 2.028D0B940TH3000000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Black (RAL 9005) | 30° |
| 2.028D0C940TH3000000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Grey (RAL 9006) | 30° |
| 2.028D0A940TH3000000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | White (RAL 9003) | 30° |
| 2.028D0B940TH4500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Black (RAL 9005) | 45° |
| 2.028D0C940TH4500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Grey (RAL 9006) | 45° |
| 2.028D0A940TH4500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | White (RAL 9003) | 45° |
| 2.028D0B940TH5500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Black (RAL 9005) | 55° |
| 2.028D0C940TH5500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | Grey (RAL 9006) | 55° |
| 2.028D0A940TH5500000 | 2700Lm | 30W | 4000K | (RA) >98 Full spec | White (RAL 9003) | 55° |
